Comunica Introduction

Knowledge Graphs on the Web
are a multifaceted story

• Publication APIs
• Access patterns
• Query languages
• ...

Difficulties for app developers

• Distinguishing APIs

  What kind of API is this?

• Interacting with APIs

  How to efficiently get data from this API?

• Combining APIs

  How to combine data across different APIs?

Abstract access to Knowledge Graphs

Hide the complexities of reading and writing for app developers

↔ ↔

Image credit

Queries as abstraction layer

• Say what needs to happen, not how

  Declarative queries hide complexities of data retrieval

• Queries are reusable

  Queries are not API-specific

• Execution via a generic, reusable query engine

  Abstracts away complexities for executing queries
  New optimisations can be used by merely updating query engine

Heterogeneity and Federation

• Understanding any source

  Give it any URL, and Comunica will aim to query it as efficient as possible
  Linked Data documents, Triple Pattern Fragments, SPARQL endpoints, ...

• Combining multiple sources

  Data can be spread over multiple sources

• Future: source discovery

  All relevant sources may not always be known beforehand
  For fully decentralised data (Solid)

Flexible and Modular Meta-Query Engine

• Collection of building blocks

  Independent modules implement specific functionality

• Combining building blocks

  Building custom query engines with specific functionality and settings
  Using a flexible configuration system

• Presets

  Pre-compiled configurations for common combinations of functionality
  Comunica SPARQL, Comunica Solid, ...

Comunica is Open

• Open standards

  Implements Web standards (SPARQL, RDF, ...)
  Implemented using Web standards (JavaScript)
  Interoperable with other TS/JS libraries using the RDF/JS interfaces

• Open source

  MIT-licensed: https://github.com/comunica/comunica

• Open governance

  Comunica Association connects organisations


Comunica Association: a non-profit

• Members and sponsors

  Financing core maintenance to advance the roadmap
  Members collectively determine roadmap


• Bounties

  Organisations can place bounties on specific issues
  Developers can get paid for resolving issues

💻 Usage on the command-line

• Installing Comunica SPARQL globally

  $ npm install -g @comunica/query-sparql

• Running a SELECT query

  $ comunica-sparql https://fragments.dbpedia.org/2016-04/en \
      "SELECT * WHERE { ?s ?p ?o } LIMIT 100"

• Running a CONSTRUCT query

  $ comunica-sparql https://fragments.dbpedia.org/2016-04/en \
      "CONSTRUCT WHERE { ?s ?p ?o } LIMIT 100"

💻 Usage in an app

• Installing Comunica SPARQL locally

  $ npm install @comunica/query-sparql

• Creating a new engine

  const myEngine = new QueryEngine();

• Running a SELECT query

  myEngine.queryBindings(...);

💻 Federated querying

• Execute a SPARQL query over multiple sources

  The sources field in the context accepts an array of sources

Advanced topics

• Architecture

  Actors, mediators, buses

• Query plan

  Inspecting the query execution flow

• Alternative configurations

  Different ways of executing queries

Modularity using the actor model

Logic is separated into different actors

Each actor independently performs a specific task.

• JSON-LD parsing actor
• Turtle parsing actor
• SPARQL union actor A
• SPARQL union actor B

Actors can be combined for solving more complex tasks

Actors are grouped in task-specific buses.

Mediators are responsible for selecting an actor to solve a certain task.

Example: Parse as fast as possible

Overview of actors and buses

Modules are wired together through semantic configuration files

Components.js: a semantic dependency injection framework.

Configuration files declare and parameterize actors, mediators and buses.

Links all the building blocks together, without having to do this in the code!

Query plan

Blueprint of how the engine executes a query

• Based on SPARQL Algebra

  Algebraic representation of SPARQL queries
  Easier to work with for query engines than strings

• Has a big impact on query performance

  The difference between query execution in 1 ms vs 1 hour

• Query planning

  The act of optimising a query's algebra
  Adaptive query planning: optimising at runtime

💻 Explaining query plans

• How is a query being parsed to algebra

  $ comunica-sparql https://fragments.dbpedia.org/2016-04/en \
    -q 'SELECT * { ?s ?p ?o } LIMIT 100' --explain parsed

• Inspecting the logical plan

  $ comunica-sparql https://fragments.dbpedia.org/2016-04/en \
    -q 'SELECT * { ?s ?p ?o } LIMIT 100' --explain logical

• Inspecting the physical plan

  $ comunica-sparql https://fragments.dbpedia.org/2016-04/en \
    -q 'SELECT * { ?s ?p ?o. } LIMIT 100' --explain physical

Alternative configurations

Different engines can be built by plugging in other components

• Comunica SPARQL Solid

  Querying over Solid pods via authenticated requests

• Comunica SPARQL Link Traversal

  Following links between documents

• Comunica SPARQL Reasoning

  Querying over implicit information via inference

Comunica abstracts access
to Knowledge Graphs

• Via declarative queries

  SPARQL, GraphQL, ...

• Runs anywhere

  CLI, client-side (browsers), server-side (Node.js), ...

• Open

  Anyone can use it and contribute
