GraphQL Tutorial
Client-side GraphQL

Ruben Taelman

Olaf Hartig

ISWC 2019, Auckland, 26/27 October 2019

Client-side GraphQL

GraphQL Tutorial

1Ghent University – imec – IDLab, Belgium

2Department of Computer and Information Science (IDA) — Linköping University, Sweden

How to practically query with GraphQL?

Notes

GraphiQL is a browser-based IDE
for GraphQL querying

https://metaphysics-production.artsy.net/

GraphQL interfaces accept HTTP GET

Requests require the query parameter.

GraphQL query must be URL-encoded.

We can just query them via the command-line with tools like curl:

curl "https://metaphysics-production.artsy.net/\
?query=%7Barticles%7Btitle%20author%7Bname%7D%7D%7D"

Outputs JSON:

{"data":{"articles":[{"title":" 5 questions for Liao Zhixin ",...

GraphQL interfaces accept HTTP POST

The query can be passed as application/json body.

curl \
    -X POST \
    -H "Content-Type: application/json" \
    -d '{ "query": "{articles{title author{name}}}" }' \
    https://metaphysics-production.artsy.net/

Outputs JSON:

{"data":{"articles":[{"title":" 5 questions for Liao Zhixin ",...

Querying from JavaScript

const query = `{
    articles {
      title
      author { name }
    }
  }`;
fetch('https://metaphysics-production.artsy.net/', {
  method: 'POST',
  headers: {
    'Content-Type': 'application/json',
    'Accept': 'application/json',
  },
  body: JSON.stringify({ query })
})
  .then(r => r.json())
  .then(data => console.log('data returned: ', data));

apollo-fetch simplifies querying
in JavaScript

Allows a fetcher to be created for a specific interface by URL.

const { createApolloFetch } = require('apollo-fetch');
const url = 'https://metaphysics-production.artsy.net/';
const fetch = createApolloFetch({ url });

fetch({
  query: `{
    articles {
      title
      author { name }
    }
  }`,
  variables: { ... },
}).then(res => console.log(res.data));

FetchQL is a lightweight alternative

const FetchQL = require('fetchql');
const url = 'https://metaphysics-production.artsy.net/';
var fetch = new FetchQL({ url })
fetch({
  query: `{
    articles {
      title
      author { name }
    }
  }`,
  variables: { ... },
}).then(res => console.log(res.data));

Apollo: a fully-featured GraphQL platform

Apollo

Main features:

(+): Team plan; (++): Enterprise plan

Apollo Client

A generic GraphQL client that can be plugged into various frameworks.

For example: React, Angular, Vue, ...

import ApolloClient from "apollo-boost";

const uri = "https://metaphysics-production.artsy.net/";
const client = new ApolloClient({ uri });

client.query({
  query: gql`{
    articles {
      title
      author { name }
    }
  }`
}).then(res => console.log(res.data));

Configuring Apollo Client in React

Adding the ApolloProvider to your React app

import { ApolloProvider } from "react-apollo";

const App = () => (
  <ApolloProvider client={client}>
    <div>
      <h2>My first Apollo app 🚀</h2>
    </div>
  </ApolloProvider>
);

Executing GraphQL queries in React

import { Query } from "react-apollo";
import { gql } from "apollo-boost";
const Articles = () => (
  <Query query={gql`{
      articles {
        title
        author { name }
      }
    }`}>
    {({ loading, error, data }) => {
      if (loading) return <p>Loading...</p>;
      if (error) return <p>Error :(</p>;
      return data.articles.map(({ title, author }) => (
        <div key={title}>
          <p>{title}: {author.name}</p>
        </div>
      ));
    }}
  </Query>);

Apollo Client advanced configuration

Cache: Client-side caching for repeated queries (in-memory or custom)

Link: An abstract way of influencing GraphQL query execution

The Gatsby framework
for React-based static Web apps

Generates Progressive Web App: pre-builds pages for faster serving.

Client-side JavaScript can still make pages dynamic.

Support various datasources including GraphQL.

Gatsby

GraphQL Client Alternatives

Apollo is the most popular platform, used by Airbnb, Twitch, Medium, ...

In Summary

Sources
